Huawei NE40 CR5D0EFGFA70 24 - Port 100 / 1000Base - X - SFP Flexible Card A ( P51-A )

Name: Huawei NE40 CR5D0EFGFA70 24 Port 100 1000Base X SFP Flexible Card A P51A
Brand: Huawei
Price: 1 USD

Buy cheap Huawei NE40 CR5D0EFGFA70 24 - Port 100 / 1000Base - X - SFP Flexible Card A ( P51-A ) product

Brand Name : Huawei

Model Number : CR5D0EFGFA70

Certification : CE

Place of Origin : CHINA

MOQ : 1UNIT

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 100 Units/Month

Delivery Time : 2-3days

Packaging Details : NEW IN BOX

Model : CR5D0EFGFA70

Number of Ports : 24

Switching Capacity : 48 Gbps

Lead time : 2-3 days

Packet Forwarding Rate : 35.7 Mpps

Data Transfer Rate : 1 Gbps

Condition : New Factory Sealed

Contact Now

Huawei NE40 CR5D0EFGFA70 24-Port 100/1000Base-X-SFP Flexible Card A(P51-A)

1 . Description:

The NE40E series Universal Service Router (USR) is a high-end network product that features line-rate forwarding capability, a well-designed Quality of Service (QoS) mechanism, strong service-processing capability, and excellent expansibility. It can be deployed at the edges of Internet Protocol (IP) backbone networks, IP Metropolitan Area Networks (MANs), Internet Data Centers (IDCs) networks and other large-scale IP networks. The NE40E can provide comprehensive services for enterprises and residential areas as a universal edge device.

Based on distributed hardware forwarding and non-blocking switching technologies, the NE40E provides maximum 480G line cards to satisfy the increased demand for bandwidth.

Huawei NE40 CR5D0EFGFA70 24 - Port 100 / 1000Base - X - SFP Flexible Card A ( P51-A )

Item	Specifications
Silkscreen of the board name	P51-24xFE/GE-SFP-A
Power consumption (typical value)	37 W
Heat dissipation	120.0 BTU/hour
Board weight	1.0 kg (2.21 lb)
Dimensions (H x W x D)	37.2 mm x 178.7 mm x 193.3 mm (1.46 in. x 7.04 in. x 7.61 in.)
Lowest Software Version	V800R006C20

Product specifications of the 24-Port 100/1000Base-X-SFP Flexible Card A

Item	Specifications
Interface type	SFP
Reliability and availability	Supporting hot swap
NMS	Enhanced command-line interface SNMP and MIB support
Operating conditions	Long-term ambient temperature: 0°C to 45°C (32°F to 113°F) Short-term ambient temperature: -5°C to +55°C (23°F to 131°F) Long-term relative humidity: 5% to 85% Short-term relative humidity: 5% to 95%
Storage conditions	Storage temperature: -40°C to +70°C (-40°F to 158°F) Storage humidity: 5% to 95%

Huawei NE40 CR5D0EFGFA70 24 - Port 100 / 1000Base - X - SFP Flexible Card A ( P51-A )

Product Tags:

huawei sfp transceiver

sfp optical module

Huawei NE40 CR5D0EFGFA70 24 - Port 100 / 1000Base - X - SFP Flexible Card A ( P51-A ) Images
